Remote Monitoring and Control for connected home appliances and operation via smartphone or tablet (only in countries where Home Connect service is available)
The Home Connect functionality can be extended by integrating numerous applications from external cooperation partners (partnerships)
Voice Control enabled via popular voice assistants (only in countries where this service is available)
Interval function: available via Home Connect
Silence function: available via Home Connect
Features
Fully automatic hood
Hob-Hood control (with Wi-Fi enabled hob)
climateControl Sensor
3 power levels and 2 intensive settings
Touch control
The standard functions are located on the right-hand user interface
Efficient BLDC technology
Automatic intensive revert (6mins)
Automatic after running (Automatic after running (10 minutes))
2 metal grease filter cassettes
Saturation indicator for metal and charcoal filter
The filter service button automatically lifts filters into service position for easy removal
Design
90 cm wide
Installation: integrated
The glass panel can be easily removed and cleaned
Suitable for installation in an island or Semi-island kitchen solution
Performance
Suitable for ducted extraction and recirculation
For recirculated extraction Clean Air Plus recirculation kit (accessory) needed
Extraction rate according to EN 61591 ø 15 cm:
max. Normal use519m³/h
Intensive833 m³/h
Noise level according to EN 60704-3 and EN 60704-2-13 exhaust air:
Max. normal use:62dB(A) re 1 pW
Intensive:71 dB(A) re 1 pW
With the Clean Air Plus recirculation kit (available as optional accessory) your appliances reaches:
Extraction rate in recirculation mode: Max. normal use:456m³/h
Intensive:596m³/h
Noise level in recirculation mode: Max. normal use:66dB(A) re 1 pW
Intensive:71 dB(A) re 1 pW
Planning and installation information
Extension height 250 mm
Dimensions (HxWxD): 709 x 918 x 140 mm
Built-in dimensions (HxWxD): 703 x 854 x 123 mm
Extractor hose 150 mm
Electrical cable length 1.3 m
Please reference the built-in dimensions provided in the installation drawings
Not suitable for combination with gas hobs
Consumption Data
Energy Efficiency Class: A (at a range of energy efficiency classes from A+++ to D)
